CM Series – ceramic sensor, pressure resistant
Eddy current sensors detect the distance or the change to metal objects without contact, dynamically and extremely accurately. The TX electronics which are specially adapted to the respective sensor calculate an analogue output signal proportional to the distance. In addition, there is a USB and CAN interface for reading the data. The eddylab software developed by eddylab GmbH is the perfect complement to the TX series with its 3 functional areas (oscilloscope, FFT analysis, data logger).
| Range | 0,3 – 2 mm |
| Linearity max. | ±0.15 % |
| Resolution | 0,03 µm |
| Pressure resistance | 200 bar |
| Protection class max. | IP68 |
| Operating temperature | up to +185 °C |
| Output* in conjunction with TX basic module | 0…10 V, 0…5 V, ±5 V, 0…20 mA, 4…20 mA USB, CAN |
